RCCC04R Cutter Crusher

The Rammer RCC Cutter-Crusher range models feature dual cylinders and a robust design. The RCC Cutter-Crusher range models are an efficient alternative to other demolition methods and are ideally suited to environmentally sensitive applications where low vibration, noise and duct are of concern, and thanks to two powerful cylinders, the 360° rotation and the materials used, this attachment is the best solution for standard and high reach demolition.

The RCC04R Cutter-Crusher is designed specifically for primary demolition and for use with mini and robot carriers. Both cylinder feature a hydraulic booster, which intensifies the input pressure, dramatically increasing the power-to-weight ratio, and supplying the performance that you would only normally see from much larger attachment. The RCC04R unique jaw design allows for large opening whilst maintaining its light structure. Applications: Primary Demolition, Material Handling, Secondary Demolition and
Structural Steel.

Features

    SPECIFICATIONS:
    Weight
    Max. jaw opening
    Operating flow
    Cutting blade length
    Pressure line connection (IN)
    Return line connection (OUT)
    Optimum oil temperature
    Allowed oil temperature range
    Optimum oil viscosity at operating temperature
    Allowed viscosity range
    Carrier weight, range *1
    290kg (640lb)
    440mm (17.32in)
    65 l/min (17.2 gal/min)
    85 mm (3.35in)
    1/2" BSP
    1/2" BSP
    40 - 60 °C (104 - 140 °F)
    -20 -80 °C (-4 - 176 °F)
    30 - 60 cSt
    20 - 1000 cSt
    3 - 6 t (6600 - 13200 lb)
    Additional information:

    *1 Check carrier allowed attachment weight from carrier manufacturer. Check application requirements.

    Specifications are subject to change without notice, 2016-11-08 11:55 by sdavis

    Product Description

    The RCC04R Cutter-Crusher is designed specifically for primary demolition and for use with mini and robot carriers. Both cylinder feature a hydraulic booster, which intensifies the input pressure, dramatically increasing the power-to-weight ratio, and supplying the performance that you would only normally see from much larger attachment. The RCC04R unique jaw design allows for large opening whilst maintaining its light structure. Applications: Primary Demolition, Material Handling, Secondary Demolition and
    Structural Steel.
